GPON interface（NNI）：1 x XG-PON interface |
Optical port | CLass N2a optical system |
Optical connector | SC/UPC |
Receiving Sensitivity | -28dBm |
Overload optical power | -8 dBm |
Transmitting Optical Power | 0.5~5dBm |
Transmit rate | 9.953Gbit/s downstream; 2.488Gbps upstream |
Wavelength | Receiving（DOWN）:1577nm；Transmitting（UP）:1270nm |
Authentication | SN/ Password/LOID /LOID+Password authentication |
User Network Interface（UNI）：4GE+1POTS+AX3000 WiFi 6+1USB2.0+1USB3.0 |
Ethernet Port | • Ethernet port-based VLAN tags and tag removal |
• VLAN transparent and aggregation |
• MAC address learning |
• Q-in-Q |
• Auto-adaptive 10 Mbit/s, 100 Mbit/s or 1000 Mbit/s |
POTS Port (option) | • SIP/H.248 |
• Call waiting, Inconditional Call Forward, Call Forward if Busy,Call Forward if no reply and Three-party calls. |
• G.711A/U, G.729 and G.722 encoding/decoding |
• SDP protocol (RFC 2327 and RFC 4566) |
• T.30/T.38/G.711 fax mode |
• DTMF |
• Emergency calls (with the SIP/H.248 protocol) |
WLAN | • IEEE 802.11 b/g/n/ax (2.4G), |
• IEEE 802.11 a/n/ac/ax (5G) |
• 2× 2 MU-MIMO (2.4G) |
• 2× 2 MU-MIMO (5G) |
• Antenna gain: 5 dBi，2 external antenna |
• 2.4G&5G concurrent |
• Air interface rate:574 Mbit/s (2.4G); 2402 Mbit/s(5G) 2.4G:2X2,11 ax ,support max 40MHz frequency bandwidth in 574Mbps rate 5G:2X2,11 ax ,support max 180MHz frequency bandwidth in 2402Mbps rate |
• EIRP reach 2.4G:18 dBm, 5G: 21 dBm |
• OFDMA,MU-MIMO,1024QAM,180MHz frequency bandwidth |
• WMM,WPS |
• Multiple SSIDs |
USB port | • USB2.0/USB3.0 |
• FTP-based network storage |
• File/Print sharing based on SAMBA |
• DLNA DMS/UPnP AV (media server） |
Product Function |
GPON | • ITU-T G.987.1-4 |
• ITU-T G.988 |
• 32 TCONTs /256GEM ports |
• 8 Egress queues per TCONT at least |
• VLAN or VLAN plus priority gem mapping mode |
• Performance monitoring: eth/Gem port |
• Dying gasp |
Layer 2 Features | • MAC learning (SVL)/aging |
• Support max frame length to 1518 bytes |
• VLAN tagging for untagged packets |
• Support VLAN 1-4094 |
• VLAN transparent/translation |
Layer 3 Features | • PPPoE/Static IP/DHCP/Bridge |
• NAT |
• Port forwarding |
• ALG, UPnP |
• DDNS/DNS server/DNS client |
• IPv6/IPv4 dual stack,and DS-Lite |
• Static/Default routes |
• Multiple services on one WAN port |
• RIPv2 with passive mode |
Multicast | • IGMP v2 (RFC 2236) and IGMP v3 (RFC 3376) |
• IGMP snooping and IGMP Proxy |
• MLD v1/v2 |
Qos | • Support 8 Queues with Strict Priority |
• Ethernet port rate limitation |
• SP/WRR/SP+WRR |
• Service flow classification |
Security | • Firewall |
• MAC/Port/URL Filter |
Management | • OMCI/TR069 |
• Web UI（Http by LAN and WAN） |
• Telnet（Telnet by LAN and WAN） |
• Dual-system software backup and rollback |
Physical Performance |
Dimensions ( W x Dx H) | 18.7CM*12.6CM*4CM(without external antenna and pads) |
Weight | About 400g |
Working temperature | 0°C ~ 45°C |
Working humidity | 5% RH to 95% RH (non-condensing) |
Power adapter input | 100–240 V AC, 50 / 60 Hz |
System power supply | 12V DC, 2A |
Power consumption | <20W |
System Configuration |
|
Main Chip | ZTE ZXIC ZX279131, 1.2GHz Dual core |
RAM | 512MB |
Flash | 256MB |
WiFi Chip | MTK MT7976DN（RF front-end chip）+MT7916AN（WIFI Baseband chip ） |
